JX-300XP
Technological features
1. Innovative technologies:
• Modern network solutions
• Using the achievements of microelectronics
• Advanced signal processing algorithms
• High-speed industrial communications
2. Architectural advantages:
• Reliable software platform
• Fieldbus support support
• Powerful microprocessors
• Optimized control algorithms
3. Operational characteristics:
• Increased stability
• Improved failure tolerance
• Configuration flexibility
• Simplicity of scaling
Areas of application:
✓ Chemical industry
✓ Oil refining
✓ Energy
✓ Metallurgy
✓ Pharmaceuticals
Advantages for users:
✔ Adaptation to complex technological processes
✔ Reducing operating costs
✔ Simply integrate with existing systems
✔ Compliance with international standards
The JX-300XP system provides effective management of production processes of various complexity.
The advantage of the product
Technical characteristics of the system (translation into Russian)
1. Security
• Compliance with international standards of industrial safety and electromagnetic compatibility
• Full redundant on critical components:
• Power Supply Module
• Controllers
• I/O Modules
• Communications
2. Ease of operation
• Intuitive user interface
• Simplicity of equipment installation
• Lightness of maintenance
• Standardized and unified components
3. Reliability
• multi -level protection against external influences:
• working temperature range: -20 ° C ...+70 ° C
• Humidity resistance: 10% -90% RH (without condensation)
• CE Certificate
• Compatibility with G3 conditions (strong pollution)
4. Real time
• Quick logic management:
• Fastest scan cycle 20 ms
• Sequence of Events (SOE):
• Accuracy 0.5 ms
5. Flexibility
• Optimized layout layout:
• High installation density
• Easy of maintenance
• Powerful configuration in:
• Support for various control schemes
• Flexibility of configuration
Additional parameters from the table:
• Storage temperature: -40 ° C ...+85 ° C
• Storage humidity: 5% -95% RH
• Atmospheric pressure: 62-108 kPa
• Power: 220 V ± 10%, 50 Hz ± 5%
• grounding resistance:
• Standard: ≤4 Ohm
• Special: ≤1 Ohm
• degree of protection: IP50
• EMS: Level 3
The system provides high reliability in various industrial operating conditions!
Video about the product
Product operating manual
1. Quick start
• System launch:
✓ Hold the power button 3 seconds
✓ Select "Setting mode" on the touch screen
✓ Follow step -by -step instructions (entry of parameters, downloading materials)
2. Intellectual interaction
• Multimedia support:
✓ Scan the QR code for access to video instructions
✓ Press the icon '? ' For a contextual reference (for example: 'calibration of sensors ')
✓ Automatic diagnosis of faults with ready -made solutions
3. Personalization
• Save the settings:
✓ Create profiles in the 'User settings ' section \
✓ Store the frequently used parameters (temperature curves, threshold values)
✓ quick password/fingerprint password
System features:
• response time ≤0.5 sec
• Support for 8 interface languages
• Automatic maintenance of a journal of operations
• Compatibility with mobile devices through Wi-Fi
For optimal work, it is recommended:
1. Regularly update software
2. Carry out preventive maintenance every 500 hours of work
3. Use only original components
JX-300XP combines the simplicity of management with professional industrial automation capabilities!
