Compressor control system (T5100)

The main functional modules

1.   Optimization of compressors management

• The use of advanced international algorithms:

• Anti -Surgut regulation

• performance control

• speed control

• steam selection management

• Fields of application:

✓ Centrifugal compressors

✓ axial compressors

✓ Technological processes without safety requirements

2.   Balancing of steam networks

• Used technologies:

• Automatic pressure regulation

• Intellectual load distribution

• Optimization of energy consumption

• Main industries:

✓ Petrochemical enterprises

✓ Chemical production

✓ Energy objects

Technical advantages:

• Improving the efficiency of equipment by 15-20%

• Reducing energy consumption to 25%

• Improving the stability of technological processes

• Complete control automation

System characteristics:

• Working temperature: -20 ° C ...+60 ° C

• degree of protection: IP54

• Protocol support: Modbus TCP, OPC UA

• response time: <100 ms

Areas of application:

• Compressor stations

• steam boiler rooms

• Technological installations

• Energy systems

T5100 provides intellectual management of critical equipment!

The advantage of the product

Technical characteristics of the T5100 system (translation into Russian)

1. High reliability

• hot reservation of critical components

• Support for replacing modules 'Hot '

• Corrosion protection according to the standard G3

• Adaptation to extreme conditions:

• Corrosive media

• wide temperature range (-40 ° C ...+70 ° C)

• Highland conditions (up to 5000 m)

• Explosive zones (ATEX)

• Open areas (IP65)

2. Advanced management technologies

• Patented control algorithms:

✓ accurate determination of the border of pumping

✓ multi -level equipment protection

✓ Coordination of several control circuits

✓ Decoration of mutual investment parameters

• Support for complex configurations:

• sequential/parallel connection of units

• hybrid control schemes

3. The flexibility of the configuration

• Advantages of deployment:

• Optimal price/quality ratio

• Modular architecture

• Support for various topologies:

® Star

® tire

° Ring

• Features of installation:

✓ horizontal installation in the rack

✓ compatibility with DIN-racks

✓ The possibility of combined placement of modules

Additional advantages:

• time of operating time for refusal> 100,000 hours

• Compliance IEC 61511 (SIL2)

• Support Industry 4.0

• Integration with ERP/Mes systems

The T5100 system combines industrial reliability with innovative management technologies!

Product operating manual

1. Acquaintance with the system

• Study the location of the elements on the control panel

• Use an intuitive graphic interface to configure parameters

• Check out the main functional zones:

• Control unit

• Indicator panel

• Connect connectors

2. System programming

• Available configuration methods:

• Graphic programming (FBD)

• Functional blocks (CFC)

• Text entry (ST)

• Ready -made solutions

• Recommendations:

✓ Use built-in master configurators

✓ Save backup projects

3. Monitoring of work

• Indication system:

• Green: normal mode

• Yellow: Warning

• Red: accident

• Blue: Service mode

• Recommended actions for accidents:

1) fix the error code

2) Check the corresponding parameters

3) follow the recommendations of the system

4. Integration opportunities

• Supported interfaces:

• Ethernet/IP

• Profinet

• Modbus TCP/RTU

• OPC UA

• Communication protocols:

• IEC 61850

• DNP3.0

• IEC 60870-5-104

The advantages of the system:

• Setting time is reduced by 40% due to an intuitive interface

• Support for 98% of industrial equipment in the market

• Possibility of integration with SCADA/MS systems

• Update for no production stop

To obtain additional information, contact the technical documentation or to the support service.
