MPS5000
Key functions
1. Continuous monitoring:
• 24-hour online control of the state of equipment
• compliance with the API670 standard
2. Multifunctional analysis:
• signal collection:
® phase marks
® vibration (displacement, speed, acceleration)
• Analysis in:
Ft of the temporary area
® frequency area
3. Protective functions:
• Real parameter display time
• Continuous comparison with the charters:
® warning alarm
® emergency shutdown
• instant operation when exceeding permissible values
Technical features:
• sampling frequency: up to 10 kHz
• Dynamic range: 80 dB
• reaction time: <20 ms
• Support up to 32 measurement channels
Areas of application:
✓ turbines and compressors
✓ pumping units
✓ generator settings
✓ Fan equipment
Advantages:
✔ Risk of risk of emergency refusal
✔ Early detection of faults
✔ Optimization of maintenance
✔ compliance with international standards
MPS5000 provides reliable protection of your critical equipment!
The advantage of the product
Monitoring and protection system for rotating equipment
1. The main purpose
Designed for continuous online control and protection of medium/large rotary units:
• round -the -clock state monitoring
• Vibration protection
• Diagnosis of malfunctions
• Full compliance with the API670 standard
2. Functionality
• Monitoring of parameters:
✓ phase marks
✓ Rotation frequency
✓ Vibration of the shaft
✓ axial displacement
✓ thermal expansion
✓ eccentricity
✓ Vibration of the case
• Analytical methods:
• temporary analysis
• frequency analysis
• Trend analysis
• Demodulation of the envelope
• Protective functions:
✓ Continuous comparison with charters
✓ Instant power when exceeding
✓ multi -level alarm (warning/emergency)
✓ automatic shutdown of equipment
Technical advantages:
• Measurement accuracy: ± 1% from the scale
• response time: <20 ms
• Support up to 64 channels
• Interfaces: Ethernet, Modbus, OPC UA
Application:
• Compressor stations
• TURBOGEENERIARY
• Pumping units
• Ventilation equipment
The system provides maximum reliability of critically important equipment!
Product operating manual
Module installation instructions
1. Precautions
Put antistatic gloves before starting work.
2. Consumed check
Make sure the type of module corresponds to the slot:
• Data interfaces → M01 slots, m02 of the main chassis
• Other modules → slots m03-m18
* Note:* modules of phase marks/rotation frequencies are installed in the slots M03, M04 in the first place.
3. Inspection of connectors
Check the integrity of the contact pins on the rear panel of the module.
4. Installation of the rotation axis
Combine the rotary pin of the module with the guide groove of the slot.
5. Fixation of the module
Smoothly insert the lower part of the module into the slot to click.
6. Fastening
Tighten the fasteners of 0.6-0.8 N · m.
7. Check
After feeding, make sure of normal indication:
• Green: working mode
• Red: error
• FIRE: Initialization
Additional instructions:
✓ All work is performed with disabled nutrition
✓ Use only standard fasteners
✓ When replacing modules, update configuration in the
✓ In case of malfunction, contact the service center
Technical support contacts:
• Tel.: +7 (495) 123-45-67
• Email: support@supcon.ru
• Emergency service: 24/7
