Industrial-Grade Amphibious Spherical Intelligent Robot | Unfriendly Environment Inspection & Monitoring

It can work for a long time in unfriendly environments such as complex terrain, extreme weather, flammable and explosive areas. Adopting a spherical structure + pendulum drive design, it has L4-level autonomous driving capability and supports standardized mounting interfaces. It can realize unmanned operations such as inspection, monitoring and disposal in industrial scenarios, with continuous operation ≥8 hours, meeting the security needs of key fields.
Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
snapchat sharing button
telegram sharing button
sharethis sharing button
  • ROTUN

1. Super Strong Environmental Adaptability: Protection level up to IP68, supporting Ex-d-IIB explosion-proof type, working in the temperature range of -25~65℃. It can resist level 8 wind (20.7m/s), heavy rain (140mm rainfall in 12 hours) and magnitude 5.5 earthquake, adapting to harsh industrial environments.


2. Efficient Motion Performance: Instant maximum speed 35km/h, acceleration only 2.5 seconds, maximum climbing angle 17°, obstacle surmounting height 300mm. Rolling motion has low friction, energy efficiency is 5~6 times that of legged robots, with continuous driving ≥100km, reducing endurance anxiety in industrial scenarios.


3. L4-Level Autonomous Navigation: No need for high-precision electronic maps. It integrates a panoramic perception system (bionic insect compound eye principle) to obtain environmental information in real time. It can automatically adjust posture when encountering potholes and collisions, realizing fully autonomous path planning and obstacle avoidance, reducing manual intervention costs.


4. Flexible Load Expansion: Equipped with multiple standardized external mounting interfaces, supporting users to customize and develop business loads. It can adapt to different needs such as industrial detection, monitoring and disposal, improving scenario reusability.

  1. Basic Specifications Diameter 800mm, Weight 150kg

  2. Power & Endurance Battery Capacity 2400Wh, Charging Time ≤3h; Continuous Operation ≥8h, Continuous Driving ≥100km

  3. Motion Performance Instant Maximum Speed 35km/h, Rated Maximum Speed 18km/h; Acceleration Time 2.5s, Deceleration Time 2.8s; Minimum Turning Radius 1.6m

  4. Protection & Safety Protection Level IP68, Explosion-Proof Type Ex-d-IIB; Maximum Working Noise ≤45dB; Lightning Protection Severe Level 4

  5. Environmental Tolerance Temperature -25~65℃; Resists heavy snowstorm (15mm snowfall in 12h), dense fog (visibility 50m), large hail (diameter 50mm)

  6. Certification Standards Complies with ISO-9001, GB/T19001-2016, ISO8001:2015 Standards

1. Petrochemical Parks: Replace manual inspection in corrosive, flammable and explosive environments. Real-time monitor risks such as equipment leakage and abnormal temperature. With explosion-proof design, it reduces personal safety hazards and improves inspection frequency and accuracy.


2. Underground Pipe Galleries: Adapt to dark, narrow and complex terrain. With long endurance (≥8h) and autonomous navigation, it detects pipe gallery structure damage and pipeline leakage, reducing the workload of manual entry into confined spaces.


3. Energy Facilities (Power Plants/Substations): Resist extreme weather such as heavy rain, snowstorm and lightning. 24-hour monitoring of transmission equipment status, timely feedback of fault signals, ensuring stable energy supply and reducing manual operation difficulty in bad weather.


4. Industrial Plant Perimeter: Realize unmanned security patrol. With collision resistance and fast movement capability (35km/h instant speed), it can link with monitoring systems to identify illegal intrusion, improving the efficiency of plant boundary security protection.

Frequent Questions
  • 1. Is the robot compliant with safety standards for use in explosion-proof areas?
    Created with Sketch.
    形状 Created with Sketch.
    Supports Ex-d-IIB explosion-proof type, meets industrial explosion-proof requirements, and can work safely in flammable and explosive scenarios.
  • 2. Can it complete industrial inspection normally without high-precision maps?
    Created with Sketch.
    形状 Created with Sketch.
    Equipped with L4-level autonomous driving, integrates sensor information, no need for high-precision maps, adapting to unknown industrial terrain.
  • 3. How long can one charge meet the needs of plant inspection?
    Created with Sketch.
    形状 Created with Sketch.
    Continuous operation ≥8 hours, driving ≥100km, covering the daily inspection needs of small and medium-sized plants.
  • 4. Can industrial-specific detection equipment (such as gas detectors) be installed?
    Created with Sketch.
    形状 Created with Sketch.
    With standardized mounting interfaces, it supports customized installation of industrial equipment such as gas detection and temperature sensing.
