Autonomous controlled time server (ATS3800)

Functionality

• up to 14 expansion slots:

✓ TTL

✓ RS485/RS232 Interfaces

✓ Optical modules (Fiber)

✓ OC outputs

• Supported signals:

• PTP (IEEE 1588)

• NTP/SNTP

• IRIG-B (DC)

• pulsed signals (PPS/PPM/PPH/PPD)

• DCF77

• Consistent messages

Management and monitoring

• Support for standards:

✓ IEC 61850

✓ DL/T860

• Management interfaces:

• Web interface

• SNMP (V1/V2/V3)

• Specialized software

Constructive features

• Corps: aluminum alloy

• cooling: passive (without a fan)

• Sustainability to:

• high levels of EMS

• extreme industrial conditions

• highlands (up to 5000 m)

Technical parameters:

• Synchronization accuracy: ≤100 ns

• Long -term stability: <1 μs/day

• working temperature: -40 ° C ~ +75 ° C

• degree of protection: IP40

• Power: 110/220 in AC/DC

Application:

✓ Energy systems

✓ Industrial automation

✓ telecommunications

✓ Transport infrastructure

ATS3800 provides reliable time synchronization in the most demanding operating conditions!

The advantage of the product

Functional characteristics of devices for synchronization of the ATS3800 series

1. Monitoring and safety

• Control of temporary discrepancies

• alarm when exceeding acceptable values

• compliance with standards:

• DL/T860 (IEC 61850-MMS)

• DL/T634.5 (104)

• DL/T860 (CMS)

• SNMP

• Safe controlled components and OS

2. Sources of time

• Support up to 8 external sources:

• Double Beidou (BDS)

• RS485 interfaces

• single-moded/multi-mudwall fiber (IRIG-B)

• 2 PTP source

• Intellectual algorithm for choosing a source

3. Technical features

• Built -in high -stable oscillator:

• Standard quartz

• Optionally: heat -fixed/rubidium

• up to 14 expansion slots:

✓ TTL

✓ RS485/RS232

✓ optical (fiber)

✓ OC outputs

✓ network interfaces

4. Management and security

• Web management interface

• The function of remote update by

• Protection NTP (MD5 encryption)

5. Certification

• compliance with the requirements:

• Chinese electricity research institute

• State network corporation China

• Ministry of Industry and Informatization of China (only BDS)

Advantages:

✔ Synchronization accuracy ≤100 ns

✔ Reliable work in extreme conditions

✔ full compatibility with industrial standards

✔ Flexible configuration for various tasks

Application:

• smart energy systems

• Industrial automation

• Telecommunication networks

• Transport infrastructure

ATS3800 is a reliable solution for critical objects!

Video about the product

Product operating manual

1. Management interface

• Check out the location of the elements on the front panel:

• LCD display (7 ')

• Navigation buttons

• Indicator LEDs

• Connection ports

• Use an intuitive graphic interface for:

• Synchronization settings

• Configuration of time sources

• Diagnostics of the system

2. System programming

Available modes:

• Basic (master setting):

• Automatic configuration

• Template solutions

• Expert:

• manual input of parameters

• advanced synchronization algorithms

3. Monitoring of the condition

Color indication:

• Blue: Settings mode

• Green: normal work

• yellow: warning (discrepancy ≤1 μs)

• Red: accident (discrepancy> 1 μs)

• White: calibration

4. Integration opportunities

Supported protocols:

• PTP (IEEE 1588V2)

• NTP/SNTP

• IRIG-B

• 1PPS/1PPM

• DCF77

The advantages of the system:

✓ Setting time is reduced by 60% due to an intuitive interface

✓ 100% compatibility with the equipment of leading manufacturers

✓ Support for hot replacement of modules

✓ Update without stopping work

To activate advanced functions, contact a service engineer.
