Genius H40 AGEBE
1. Modular CPU Computing Platform
The Genie Series CPUs adopt a modular design, flexibly supporting Intel 12th Gen Alder Lake-U, 11th Gen Tiger Lake-U, 8th Gen Whiskey Lake-U Core i7/i5/i3 processors, as well as 6th/7th Gen SkyLake-U/KabyLake-U Core i7/i5/i3 and Celeron J1900.
2. Modular I/O Interfaces: Multi-Network, Multi-Serial, Customizable
• Genie Series I/O interfaces feature configurable modular design
• It supports 4-6 Ethernet ports for machine vision camera communication
• It enables EtherCAT bus motion control and communication with up to 10 RS-232/485 devices
• DIO digital I/O and CAN bus can be flexibly configured
3. High-Precision Die-Cast Aluminum with Copper-Aluminum Integrated Heat Dissipation
• The compact and rugged Genie Series utilizes die-cast aluminum unibody construction. Through thermal simulations across 10+ CPU power profiles, it achieves integrated heat pipe cooling technology that solves industry pain points, ensuring stable and reliable high-performance computing in tight spaces.
4. UPS Backup Battery for Data Security
• Optional UPS battery management automatically prioritizes data preservation during unexpected power outages. Configurable 3-10 minute countdown auto-shutdown ensures complete protection for critical production data, hard drives, software, and OS - significantly enhancing device stability and real-time operation reliability.
5. Cable-Free Design for Enhanced Reliability
• Reliability lies in details: Genie Series I/O interfaces use direct physical connections without cables, minimizing impacts from vibration, mobile operation, transportation, and poor cable connections. This eliminates external environmental factors to ensure highly efficient production.
6. Single-Side I/O & Modular Installation
• Genie Series offers unique single-side I/O and multiple mounting options. Compared to traditional dual-I/O hosts, the single-side design simplifies installation in compact spaces and streamlines field communication debugging.
• With flexible embedded/DIN rail mounting options, it is the ideal choice for AGV robot control systems and machine vision applications - effectively addressing challenges in modular computing performance, modular I/O interfaces, and customization requirements in space-constrained environments.
7. Localized Upgrades & Wireless Data Networking
• The Genie Series features removable hard drives for user-driven capacity upgrades, simplifying local maintenance while significantly reducing downtime and costs.
• In the IoT era, it enables edge computing with seamless wireless networking (4G/5G/WiFi/Bluetooth), unlocking big data value for smart factories in industrial IoT applications.
